Digital IC Fundamentals - Physical Implementation
From Floorplanning to Tapeout: A Practical Guide to Digital IC Physical Implementation
Instructor: EDA Academy
CourseAug 05, 2026All LevelEnglish
This course provides a practical and structured view of digital IC physical implementation. It explains how layout, power, clocking, routing, and optimization decisions transform logical designs into manufacturable silicon while shaping timing, power efficiency, reliability, and yield.
5.0
2students
This offering includes
- 9 modules
- 45 lectures
- Access on mobile and computer
- Certificate of completion
- 6.76 hours on-demand video
- 751.6 KB downloadable content
- 89 Quiz questions
What you'll learn
Define and apply core principles of digital IC floorplanning methodology
Analyze and design reliable power delivery networks for digital ICs
Understand placement flows and physical synthesis optimization techniques
Interpret boundary scan architecture and scan connectivity behavior
Evaluate clock network quality after clock tree synthesis
Analyze routing strategies and signal integrity effects in digital interconnects
Apply iterative optimization techniques to achieve timing closure
Coordinate extraction, verification, and mask preparation steps effectively
Define and apply core principles of digital IC floorplanning methodology
Analyze and design reliable power delivery networks for digital ICs
Understand placement flows and physical synthesis optimization techniques
Interpret boundary scan architecture and scan connectivity behavior
Evaluate clock network quality after clock tree synthesis
Analyze routing strategies and signal integrity effects in digital interconnects
Apply iterative optimization techniques to achieve timing closure
Coordinate extraction, verification, and mask preparation steps effectively
Who is this course for
Digital design engineers who want to understand physical implementation effects
Physical design engineers building a strong foundation in modern IC flows
Graduate students studying VLSI physical design and implementation
Engineers transitioning from logical design to physical design roles
SoC engineers who want better insight into timing and power behavior
Verification engineers wanting a clearer view of physical signoff concepts
Hardware engineers interested in how chips are physically built
Students preparing for careers in digital IC physical implementation
Professionals wanting a structured overview of the full physical flow
Engineers curious about routing, signal integrity, and manufacturability
Digital design engineers who want to understand physical implementation effects
Physical design engineers building a strong foundation in modern IC flows
Graduate students studying VLSI physical design and implementation
Engineers transitioning from logical design to physical design roles
SoC engineers who want better insight into timing and power behavior
Verification engineers wanting a clearer view of physical signoff concepts
Hardware engineers interested in how chips are physically built
Students preparing for careers in digital IC physical implementation
Professionals wanting a structured overview of the full physical flow
Engineers curious about routing, signal integrity, and manufacturability
Requirements
Basic knowledge of CMOS technology and standard cells
Understanding of netlists and logical connectivity
Familiarity with power, ground, and signal nets
Basic concept of routing and metal interconnect layers
Motivation to understand real-world chip implementation flows
Basic knowledge of CMOS technology and standard cells
Understanding of netlists and logical connectivity
Familiarity with power, ground, and signal nets
Basic concept of routing and metal interconnect layers
Motivation to understand real-world chip implementation flows
Description
This course presents a complete and practical view of digital IC physical implementation, focusing on how logical designs are transformed into manufacturable silicon layouts. It covers the physical decisions that determine performance, power efficiency, reliability, and yield, emphasizing how abstract intent becomes real geometry, wires, and electrical behavior.
The course starts with physical organization at the chip level. Floorplanning is used to define die area, block placement, and early physical constraints that shape all downstream results. Power planning follows, addressing how supply and ground are delivered across the chip under real current demand, voltage drop, and long-term reliability limits.
Placement and physical synthesis form the next stage, where standard cells are assigned physical locations and optimized with awareness of timing, congestion, and power. These steps establish routing feasibility and timing behavior while revealing the impact of real interconnect distances. Physical synthesis is introduced to align logical optimization with physical reality as wire delays become dominant.
Clock distribution is treated as a core physical system. The course explains how clock trees are built, how skew and insertion delay arise, and how clock modeling evolves as physical information increases. The interaction between clock paths and data paths is examined to show how clock design directly affects timing closure.
Routing transforms connectivity into metal interconnects. Global and detailed routing strategies are explained alongside signal integrity effects such as coupling, noise, and crosstalk. Timing-driven, congestion-driven, and signal-aware routing techniques are presented as coordinated methods for achieving electrical correctness and manufacturable layouts.
The course concludes with extraction, verification, and manufacturing preparation. Parasitic extraction enables accurate timing and power analysis. Physical verification and power integrity checks ensure correctness and reliability. Mask preparation converts verified layout data into fabrication-ready information, completing the physical implementation flow.
